Backscatter - AOI UWL-04A M52 Wide Angle Lens for 28mm Cameras
- 52mm Threaded Lens
- Designed for 28mm equiv. Lenses
- 160° Field of View
- 0.42X Magnification
- AOI QRS Lens Mount
- Interchangeable Mount
- Up to 160° of coverage
- Depth Rating: 60m / 200ft
With an equivalent 28mm camera you will get a 0.41x ratio... that equates to about 160° ultra wide-angle shooting! Injected into the lens is an inert gas to reduce the occurrence of cloudiness in the lens due to temperature differences. With a 52mm thread, it will fit many cameras and housings.
Includes:
- Model: AOI UWL-04A
- Description: Underwater 0.42X Wide Angle Conversion Lens (Included QRS-01-AD3)
- Lens Construction: 5 Elements in 5 Groups
- Lens Coating: All Glass Lens Elements with Multi-layers AR Coating, Front PC Dome Lens with Hard Coating
- Field of View (diagonal): 160°(with 28mm Lens)
- Magnification: 0.42X
- Minimum Object Distant: 0 mm to the Front Dome Lens
- Mount System: QRS-01
- Depth Rating: 60 Meters / 200 Ft.
- Lens Barrel / Lens Hood: Aluminum Alloy with Black Anodize / ABS
- Weight (on land / underwater): 725g (on land) / 210g (underwater)
- Dimensions: 157mm (D) X92mm (H)
- Standard Accessories: Neoprene Dome Cover (DNC-04), Rear Lens Cap (LRC-01), Carry Case (LPC-03) and Adaptor (QRS-01-AD3)
